Wall Mounted Lithium Battery Pack

Our wall-mounted lithium battery pack uses high-quality LiFePO₄ cells, offering 51.2 V nominal voltage and 10.24 kWh capacity, with 9.2 kWh of usable energy. It delivers over 6,000 cycles at 90% DOD, features IP-rated housing, and provides safe, reliable, long-term energy storage for residential or commercial applications.

Send Inquiry

Description

Introduction

Our wall-mounted lithium battery pack uses high-quality LiFePO₄ cells, offering 51.2 V nominal voltage and 10.24 kWh capacity, with 9.2 kWh of usable energy. It delivers over 6,000 cycles at 90% DOD, features IP-rated housing, and provides safe, reliable, long-term energy storage for residential or commercial applications.

Parameter

Basic Parameters	Numerical
Nominal Voltage (V)	51.2V
Nominal Capacity (WH)	10240 Wh
Usable Capacity (WH)	9216 Wh
Discharge Voltage (V)	46V
Charge Voltage (V)	56V
Recommend Charge/ Discharge Current (A)	100A
Max. Charge/ Discharge Current(A)	200(3S)
Communication	RS485/CAN/Bluetooth
Working Temperature	0-40C
Storage Temperature	-20-70C
Humidity	10%-80%
Certification	CE/ IEC/ UN38.3/ MSDS
Design Life	10 years+
Cycle Life	>6000@90%DOD(25±5c)

Description

High-Grade LiFePO₄ Cells

Utilizes high‑grade lithium iron phosphate cells with ≤5 mΩ internal resistance for stable voltage, low thermal runaway risk, and reliable performance in residential or small commercial energy storage systems.

Compact Wall‑Mount Design

Slim, space‑efficient wall-mounted enclosure weighing ~54–115 kg, supporting standard wall fixings, optimized airflow, and heat dissipation for safe indoor installation.

Voltage & Capacity Range

Nominal voltage 51.2 V, with capacity options from 100 Ah up to 280 Ah (~5.12 kWh to 14.3 kWh), allowing flexible sizing for single‑home or multi-appliance setups.

High Cycle Life & Longevity

Rated for ≥6,000 full cycles at 80% depth of discharge under 25 ± 5 °C, ensuring consistent performance and energy reliability over more than a decade of residential operation.

Advanced Communication & Monitoring

Equipped with RS‑485 and CAN interfaces, enabling precise BMS monitoring of individual cell voltages (2.5–3.65 V), pack current (0–200 A), and temperature (−20 °C to 60 °C), allowing integration with EMS, smart home, or inverter systems.

Strong Power Delivery

Continuous discharge capability of 50–100 A with short‑term peaks up to 200 A, sufficient to support typical household loads, appliances, and surge events without compromising safety or efficiency.

Applications

Ideal for residential solar-plus-storage, home backup power, and small commercial installations. This wall-mounted battery provides reliable, uninterrupted energy, integrates smoothly with inverters, and offers scalable storage solutions for homeowners and businesses seeking long-term energy reliability.
